Site Plans & Permit Drawings for Stem Projects.

Stem site-plan review, municipal zoning and construction permits

Stem has Town-level planning considerations, while Granville County's inspections and environmental agencies may control separate construction and utility approvals. A drawing for a Stem parcel should therefore start from verified property identification, mapped zoning or recorded conditions and the intended building footprint. Stem applicants can use the official municipal resource linked on this page to identify the proper application path instead of assuming a generic county-wide site-plan checklist fits every proposal.

For rural or semi-rural properties, show current parcel access and locations of any wells, septic systems, recorded easements or nearby accessory structures before building placement. A typical New-house construction drawing packages request should distinguish existing and proposed improvements and show the setback relationships that affect the actual lot. Include photographs and scaled measurements for existing structures, proposed driveways and new roof or paved surfaces. The drawing and any required construction-sheet notes must agree before being supplied to reviewers in Stem.

A new residence or post-frame shed should be scoped separately from large-scale site engineering; confirm the parcel's zoning designation and actual jurisdiction. The same Stem project may require zoning, building, environmental, utility or commercial-development reviews at different stages. Where a submission changes site access or includes structural and trade work, the site plan should be coordinated with those affected discipline drawings. A draft site exhibit is not a certified boundary survey, and zoning authorization is not equivalent to a building-code permit.

For a Stem building application, establish zoning from the correct municipal or county office, then identify the construction-code review and any separate utilities or environmental approvals. In Granville, a driveway change, septic system, structural beam or new exterior footprint can affect the sheet index in different ways. For rural or semi-rural properties, show current parcel access and locations of any wells, septic systems, recorded easements or nearby accessory structures before building placement.
